SPECIFICATIONS 5.7 VORTEC 5.7V -  MPI
CRANKSHAFT POWER RATING (CARBURETED)* 315/235 325/242 (MPI)
ESTIMATED PROP SHAFT RATING (CARBURETED) HP/KW** 293/219 N/A
ESTIMATED PROP SHAFT RATING (EFI) HP/KW** 302/225 (TBI) 302/225 (MPI)
DISPLACEMENT (LITER/CID) 5.7 / 350 5.7 / 350
CYLINDERS V-8 V-8
BORE & STROKE (INCHES) 4.00 x 3.48 4.00 x 3.48
COMPRESSION RATIO 9.4:1 9.4:1
PEAK TORQUE 358 lb-ft @ 3200 rpm 358 lb-ft @ 3200 rpm
CARBURETOR 4 BBL (HOLLEY) N/A
IGNITION DELCO ELECTRONIC DELCO ELECTRONIC
FULL THROTTLE OPERATION (CARBURETED VERSION) 4600 - 5000 N/A
FULL THROTTLE OPERATION (EFI VERSION) 4600 - 5000 4600 - 5000
ROTATION (FLYWHEEL) (Opposite Rotation Available on SportPac Only) CCW/CW
CCW/CW
TRANSMISSION - SPORTPAC ONLY HURTH OR BW HURTH OR BW
TOTAL WEIGHT - U.S. LBS. - ENPAC 710 710
TOTAL WEIGHT - U.S. LBS. - SPORTPAC W/DIRECT DRIVE 825 825
marine power engines,boat
engines,marine engines,rebuilt boat
engines,rebuilt marine
engines,crusader engines. marine
power engines,boat engines,marine
engines,rebuilt boat engines,rebuilt
marine engines,crusader
engines,marine power engines,boat
engines,marine engines,rebuilt boat
engines,rebuilt marine
engines,crusader engines.
marine power engines,boat
engines,marine engines,rebuilt boat
engines,rebuilt marine
engines,crusader engines.marine
power engines,boat engines,marine
engines,rebuilt boat engines,rebuilt
marine engines,crusader engines
::Marine power 5.7:: Inboard
Boat Store Online.com
Home
Email us
888-426-2841
5.7L / 350 CID
B350S
260hp/194kw*
1987-1995
SPECIAL SERVICE BASE ENGINE
Replaces Gen 1 Small Bock V-8 Engines With One-piece Rear Seal And Mechanical
Fuel Pump. Requires Mechanical Fuel Pump. Includes: Roller Cam Fuel Pump Push
Rod. No Intake Manifold, Flywheel, Circulating Water Pump or Harmonic Balancer.
Also Available As Opposite Rotation At Additional Cost
One Year Limited Warranty

B5.7V-COMP
315hp/235kw *
VORTEC  Style Cylinder Heads
COMPLETE SERVICE BASE ENGINE
Includes: Gen I Plus Engine with High-Flow Cylinder Heads, 14" Inboard (Reversible)
Flywheel, Intake Manifold with brass insert (intake manifold has square bore flange
pattern with no heat crossover), Harmonic Balancer, Circulating Water Pump, Dipstick
& Tube. Requires Electric Choke Carburetor.
Also Available As Opposite Rotation At Additional Cost
One Year Limited Warranty

P5.7V
315hp/235kw *
VORTEC Style Cylinder Heads
PARPAC - Partial Engine Package
Includes: Complete Service Base Engine, Carburetor, Fuel Lines, Electric Fuel Pump,
Electronic Distributor with High-Performance Coil, Ignition Wire Set.
Also Available As Opposite Rotation At Additional Cost
One Year Limited Warranty

S5.7V
315hp/235kw *
VORTEC Style Cylinder Heads
SPORTPAC - Complete Inboard Engine Available as Bobtail or with Hurth or Velvet
Drive Transmission - Includes: Parpac plus Inboard Bellhousing, Merc-Style
Center-Rise Manifolds with 4" Risers (3" Optional), Alternator, Dual Alternator Belt
Drive, 50 Amp Circuit Breaker, Heavy Duty Engine/Gear Cooler, Fuel/Wat er Separator,
Top Mount Starter, Engine Wiring Harness, Single Sender Package, Crankshaft-Driven
Auxiliary Seawater Pump, Flame Arrestor, Weather Cover, Dual Remote Oil System,
Reversible Dipstick & Tube w/Oil Drain Fitting, Superior Corrosion Resistant Urethane
Paint
Also Available As Opposite Rotation At Additional Cost
Two Year Limited Warranty
Available SportPac Engine Options Include:
Electronic Fuel Injection (Throttle Body Injection or Multi-Port Injection) ?
Fresh Water Cooling System (Front Mount or Rear Mount) $500.00
Alarm System ?
Instrument Panel with Harness Extension ? Cast Aluminum Oil Pan
* Horsepower rated @ crankshaft - Carbureted Model (EFI Model - Slightly Higher  Horsepower)
** Horsepower rated @ crankshaft - EFI Model
Price:S5.7Lv
List: LH-------$10,955.00
Your cost ---$6599.00
Marine Power engines
"Marine power 5.7/350. Check box for MPI Fuel injection $1260.00 Check box for freshwater cooling $805.00.
updated 4/23/09
